Introduction
Fire Fighting Robot (Foam Spraying) is a device specifically designed for firefighting tasks. lt is primarily used in hazardous areas like petrochemical sites, oil tank farms, large warehouses, and buildings where high temperatures, intense heat radiation, andpotential collapses make it difficult for fire trucks and personnel to access. By using the firefighting foam robot, personnel casualties can be avoided, and effective firefighting and cooling can be achieved.
Features
Features a self-developed wheel chassis with superior performance.
Utilizes a 10.1-inch screen wireless remote control, with a wireless control visibility distanceof up to 1 kilometer.
Uses an electrically controlled dual-purpose water/foam cannon with a water flow rate of 40 L/s and afoam flow rate of 96,000 L/min, enhancing firefighting efficiency.
Includes a water mist cooling system for temperature reduction, enhancing its effectiveness inhigh-temperature scenarios.
Comes with a high-capacity lithium battery, offering up to 3.5 hours of continuous operation.
Features a highly integrated handheld wireless remote control with a display that provides real-timeinformation on temperature, battery level, toxic gas concentrations, and other robot status data.
Eauipped with an ultrasonic radar obstacle avoidance system, automatically detecting obstacles andhalting movement when they are less than 50cm away.
Parameters
Battery Voltage
DC 48V
Motor Power
3.15kW * 2
Maximum Speed
1.8m/s
Autonomy
≥3.5h
Battery Capacity
200Ah
Charging Time
≤8h
IP Rating
≤IP66
Ground Clearance
165mm
IECEx Rating
Ex db eb mb llB T4 Gb
Gas Detection
EX, CO, O₂, H₂S, SO₂, NH₃, HCl, NO₂ (Customizable)
Control Mode
10.1-Inch Display with Wireless Remote Control
Minimum Turning Radius
850mm
Maximum Lifting Height
1645mm
Traction Force
5020N
Water Flow Rate
40L/s
Foam Flow Rate
96,000L/min
Foam Spray Range
≥45m
Inlet Pressure
8 bar
Foam Expansion Ratio
30~40
Foam Consumption
1.8L/s
Weight
≤560kg
Product Size
≈1690*1035*1245mm
