Introduction

The Multimodal Container Inspection System is an intelligent solution designed for container inspection at ports and border checkpoints. Integrating radar, high-precision sensors, robotic arms, and multimodal perception algorithms, the system captures internal imagery, structural depth, and other key data during the container opening process. It enables rapid identification of empty containers and concealed risks, enhancing both inspection accuracy and operational efficiency. With 24/7 operational capability and seamless integration with customs supervision platforms, the system supports fully automated, digitalized, and closed-loop inspection workflows.

Features

Non-Intrusive, Intelligent Inspection

Multimodal Data Fusion

Adaptive to Complex Operating Conditions

Scalable Algorithm Framework

High System Integration

Parameters

Rated Power

≤800W

Operating Temperature

-20℃~+65℃ (Outdoor)

Storage Temperature

-20℃~+65℃ (Outdoor)

Relative Humidity

10~90%RH,Non-condensing

Installation Environment

Fully outdoor, weather-resistant

Communication Interfaces

RJ45, USB, and RS232

Detection Time

≤15s (from vehicle positioning to inspection completion)

Detection Precision

≥330*330*330mm

Detection Accuracy Rate

≥98%

Information Storage

Stores inspection data for ≥100 containers

Equipment Dimensions

≤ 300*200*4000mm (Base: 600 × 600 mm)
