Introduction

The Empty Container Detection System adopts deep learning and acoustic signal analysis technology to realize intelligent and efficient detection of empty container/heavy container status. The equipment uses high-precision sensors, with self-detection, automatic obstacle avoidance, empty box detection, sound and light alarm, voice prompt, security protection and other functions. The equipment has short detection time, high detection accuracy safety and reliability, and can be intelligently connected with the bayonet system to achieve self-service customs clearance of vans and improve vehicle passing efficiency, and can be widely used in port, freight yard, port and other container vehicle inspection places.

Features

Frame Height Adaptive

Deep Learning Algorithm

Remote Control

Offline Analysis

Parameters

Swing Arm Control

The Swing Arm can Swing Forward and Back

Detection Distance

0~1000mm

Speaker

≥100dB

Detection Time

≤20s

Eignal Bouroo

Frequency Range 70Hz~200Hz

Detection Accurasy

≥98%

Communication interface

TCP/IP, UDP

Power Consumption

≤1200W

Rated Frequency

50Hz±5%

Input Voltage

AC 220V±10%

Max Power Consumption

≤1200W

Operating Temperature

-20°C-+65°C (Outdoor)

Storage Temperature

-20°C-+65°C(Outdoor)

Relative Humidity

10~90% RH, Non-condensing

Suitablo Containor Sizo

Standard 20 feet, 40 feet, 45 feet

nstallation Environment

Semi-outdoar

Dimension

920mm(L)*900mm(W)*2420mm(H)
