Introduction

Maxvision Embedded Palm-vein-based Recognition Terminal adopts Al recognition technology, combined with scientific applications such as vision, optics, biology , etc., uses multi-band infrared imaging technology to obtain the palm vein distribution map of the palm, and performs biometric identification through a dedicated comparison algorithm to achieve ultra-high performance. The equipment has the advantages of safety and reliability, non-contact authentication, live detection, good anti-interference, and high accuracy. lt can be embedded in access control, gates, self-service terminals andother systems, and is widely used by personnel in customs, border defense, seaports, communities, buildings access controlled premises etc..

Features

High-speed Authentication

All-angles Recognition

Recognizable with Offset

Normal Recognition of Wet Hands

Recognizable in Water Mist Environment

Backlight Recognition

Uniqueness of ldentification Characteristics

Certified with a High Level of Security

Parameters

Device Appearance

Integrated ABS Structure

Device Capacity

1GB LPDDR3, 8GB EMMC

Palm Vein Recognition Accuracy

Rejection Rate < 0.4% when False Positive Rate < 0.01%

Operating voltage

DC 12V/2A

Operating Temperature

-20°C-+60°C

Working Humidity

10%RH-95%RH

Extemal Communication

Data Transmission through LAN Port or RS232 interface. Offline Support

Operation Environment

Indoor

Installation

Embedded Standard 86 Bottom Box Mounting or Embedded Channel Mounting
