Introduction

The ANPR All-in-one Machine is an AI-powered, all-in-one solution designed to accurately identify license plates from multiple countries. Equipped with embedded deep learning algorithms, the device captures and analyzes video streams in real time to deliver fast, reliable recognition across a wide range of plate formats.

Compact and easy to deploy, the system is ideal for vehicle access control in residential complexes, shopping centers, schools, hospitals, airports, industrial parks, and public parking facilities—enabling smarter traffic management and seamless integration into modern mobility infrastructures.

Features

Accurately Recognize of Multinational License Plates

Intelligent Fill Light

Adaptive Speed Capture

High Open Configuration Capability

Black and White List

Voice Broadcast

Real-time Video Surveillance

Parameters

License Plate Recognition Rate

≥99%

Supported Vehicle Speed Range

0~30Km/h

Camera Capture Angle

≤45°

Sensor Resolution

5 MP HD CMOS

Lens

Supports motorized zoom lens

Image Format

JPEG

Image Resolution

2880*1616

Video Resolution

2880*1616 / 1920*1080 / 1280*720 / 720*576 / 640*480

Maximum Frame Rate

30fps (adjustable)

Video Compression Standard

H.264 / H.265Bitrate: 256Kbps – 8Mbps (adjustable)

Image Settings

Adjustable sharpness, saturation, brightness, contrast, image rotation, wide dynamic range (WDR), etc.

Audio

Supports voice broadcast

Network Interface

1 × 100M Ethernet

Relay Output

5

Trigger / Alarm Input

8

Serial Interface

2 × RS485

LED Display Size

304*152mm

LED Display Resolution

64*32

Fill Light

Built-in white light illuminator

Operating Voltage

AC 220V / 110V ±10%, 50~60 Hz

Power Consumption

<40W

Operating Temperature & Humidity

-40℃~+70℃, 5%~95%RH (Non-condensing)

IP Rating

IP54

Installation Method

Ground Cabinet Mounting

Dimensions

194mm(L)*130mm(W)*1340mm(H)
